Product Description:
INGKE YKT-100200NL 100% compatible with JTL-U1002NL Pulse
Part No.: JTL-U1002NL Pulse
INGKE Part No.: YKT-100200NL
Made in China: INGKE Technology
Description: JTL-U1002NL Pulse 2 Ports 10G Base-T
MOQ: 1PCS
Lead Time: 1-2 Weeks
Connector Type: RJ45
Number of Ports: 2
Number of Rows: 1
Applications: 10G Base-T
Mounting Type: Board Edge, Cutout; Through Hole
Orientation: 90° Angle (Right)
Termination: Solder
Height Above Board: 0.376" (9.55mm)
LED Color: Green, Yellow - Green
Number of Cores per Jack: 8
Shielding: Shielded, EMI Finger
Features: Board Lock
Tab Direction: Up
Contact Material: Phosphor Bronze
Contact Finish: Gold
Operating Temperature: 0°C ~ 70°C
Shield Material: Copper Alloy
Housing Material: Thermoplastic
Categories:Connectors, Interconnects, Modular Connectors, Modular Connector Jacks With Magnetics
MSL: 1 (Unlimited)
Lead Free, RoHS Compliant
INGKE UL No.: E530462
100% compatible, 100% test, warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
