YKB12-10867AFS 1542790 Phoenix Contact

Product Item : YKB12-10867AFS INGKE
Category： M12 Panel Mount Connector
A Code 8Pin Female M12
Replace 1542790 Phoenix Contact
INQUIRY EMAIL

Product Description:

INGKE YKB12-10867AFS 100% cross 1542790 Phoenix Contact

Part No.: 1542790 Phoenix Contact
INGKE Part No.: YKB12-10867AFS
Made in China: INGKE Technology
Description: 1542790 Phoenix Contact A Code 8Pin Female M12 Circular Connector
MOQ: 1PCS
Lead Time: within 1 week

Connector Type: Female Socket
Number of Positions: 8
Shell Size - Insert: M12-8
Orientation: A Code
Termination Style: Solder
Shielded: No
Contact Material: Copper Alloy
Shell Material: Zinc Die Cast
Contact Finish - Mating: Gold
Ingress Protection: IP67 - Dust Tight, Waterproof
Rated voltage: 60V
Rated current: 4A
Contact resistance: ≤ 3 mΩ
Insulation resistance: ≥ 100 MΩ
Operating Temperature: -25°C ~ 85°C
Applications: Automation Control, Industrial, Telecommunications
Moisture Sensitivity Level (MSL): 1 (Unlimited)
RoHS Compliant and REACH

100% compatible, 100% test, warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
Chinese UL factory for producing 1542790 Phoenix Contact M12 Circular Connector

Tags: 1542790 Phoenix Contact ，M12 Circular Connector
